The DSGW-023 Dual-Band Router Gateway built n 880MHz MIPS® 1004KEc™dual-core processor brings kinds of wireless and IoT capabilities into one unique solution. The smart device is designed for providing superior wireless access performance and comprehensive routing capabilities. Besides, it also wokes as a bridge that connects IoT devices and sensors to cloud-based computing and data processing. Based on the tuya zigbee module( optional), it can capture data from tuya zigbee device too.
Taking advantage of pre-integrated and comprehensive development guidance, IoT Gateway developer can develop the custom firmware on the hardware.
Features
General
- Supports input with DC 5.0V, 1A, micro-USB
- Supports 10/100 Ethernet with 802.3af PoE
- Supports firmware upgrade Over-the-Air
- Supports HTTP(support SSL/TLS)/MQTT(support SSL/TLS)
- Operating temperature: -25℃ to 65℃
Wi-Fi
- Wifi module based on the Mediatek's MT7688 575MHz 32-bit Application Processor
- 1T1R/2T2R 2.4 GHz with 150/300 Mbps PHY data rate,802.11b/g/n WiFi
- 128 Mbyte 16-bit DDR2 RAM
- 16 Mbyte SPI NOR Flash
- RGB LED strip as the status indicator
- OpenWrt, Linux distribution for embedded devices.
BLE
- It’s with silicon labs chips EFR32BG21.
- Transmit power is up to 20dBm
- Bluetooth 5.0
Typical Application
- Smart Gateway collects information about Beacon nearby, including RSSI, MAC, etc., once per second.
- Smart Gateway send the Beacon information to Cloud via Wi-Fi .
- Smart Gateway support the TCP/IP, UDP protocol, and can support the MQTT, LWM2M protocol.
- Smart Gateway support connect zigbee and z-wave devices
- Smart Gateway support Cellular network
