Zigbee Gateways

Dusun IoT’s universal Zigbee gateways can integrate Zigbee devices across various manufacturers and brands, and is able to serve as local Zigbee hub without cloud. All of our Zigee gateway hubs conforms to standard Zigbee 3.0 protocol. Do not hesitate to use our Zigbee gateways for boosting your businesses.

Zigbee gateway can also act as a bridge between Zigbee smart devices (relays & sensors & actuators) and cloud based applications and product. LTE 4G, Wi-Fi and Ethernet backhaul avaliable.

Zigbee is a wireless low-power protocol that many smart home device manufacturers prefer because it extends battery life of smart devices, like lights, switches, locks, motion sensors, and thermostats, which are in close range of each other. Thanks to Zigbee 3.0, it faclitates the interoperability among smart devices from different brands. Get to know what Zigbee is at a higher level.

Unlock the Potential of Zigbee Gateway Hubs

Arm Cortex Processors

Power-efficient, high performance, secure and OS-friendly Arm-based processors like RK3328, RK3568 to run various IoT applications.

Excellent Zigbee performance

Wireless EFR32MG21 SoC provides market-proven Zigbee protocol stack and robust RF link for reliable communications.

Zigbee-certified Products

Dusun Zigbee 3.0 gateways have CSA certification, which proves great credibility and interoperability with products from leading brands.

Customize Gateway Applications

Multiple OSs compatible like Linux, Ubuntu, Debian, OpenWRT, and Android, and Open source Java, C, C++, Python, Node.js, Java environment.

dsgw-210 multi-protocol gateway
Easy Docking with Platforms

Out-of-box integration (MQTT API offered) with various platforms to perform remote operation and management. No programming required.

Wireles s & Wired Backhauls

Wide broadband connectivity options including Cellular LTE 4G, Wi-Fi, Ethernet for deployment in any places in the world.

Multiple Protocols Supported

Flexibility to choose BLE/Zigbee/Z-Wave/LoRaWAN/Wi-Fi/Matter/Thread/GPS/M-Bus/Sub-GHz protocols to scale your businesses while saving costs.

Rich External Interfaces

RJ45, Type-C, HDMI, RS485, USB, etc., allowing for connecting any peripherals as you want.

Zigbee Hub Gateways to Manage Smart Devices

Dusun Zigbee gateway is capable of integrating BLE/Z-Wave/Matter/Wi-Fi/LTE 4G/Ethernet connectors in an incredibly compact design, allowing users to mix or match components as needed. Zigbee gateway can act as a bridge between Zigbee protocol smart devices (relays and sensors) and the WiFi-based devices, matching up to 40 end devices in tree topology and unlimited number of remote Zigbee-based devices in mesh topology.

Dusun IoT's zigbee smart home hub gateway devices have built-in Zigbee module, allowing for seamless communication between Zigbee-enabled smart home devices while relay interfacing across existing Ethernet, Wi-Fi, and cellular networks for WAN series connectivity to cloud-based software programs.
Dusun Pi gateway are a series of open source gateways, better raspberry pi smart home alternatives for you with wide connectivity options and multiple funcitons (a combination of router, gateway, PC and TV box). Home Automation software like Home Assistant can be pre-installed. High-performance in hardware and cost-efficient in configuration. A perfect selection ro bazillions of smart home device manufacturers.

The Zigbee gateway, or Zigbee router, working as the coordinator in the Zigbee network, is in charge of initializing and operating the network, assigning addresses and channels, maintaining routing tables, etc. The Zigbee router devices connect to other networks (such as the Internet, local area network, cellular network, and so on) through wired or wireless ways, and performs data conversion and encapsulation through the corresponding protocol stack.

1v1 ODM Services to Address All Complex Requests

Custom Design (RF /PCB /Structure /Software)
Prototype Manufacturing
Complete Test & Validation
Manufacturing & Quality Control
Global Delivery

Program Automation Applications on Zigbee Gateways

Applicable Users

For those who own a team of engineers to build universal Zigbee gateway solution in-house, this fully customizable Zigbee gateway hub hardware solution is definitively the best choice to run your feature-specific software and  help your businesses differentiate. Pre-certification reduces time for going to the market.

What Dusun IoT Offers

We provide guideline and jSON format data API. Users can build the custom firmware from the bottom layer. Meanwhile, we offer driver for the communication module, kernel, bootloader resource, fully-documented SDK, Zigbee 3.0 firmware, and burning tools, for helping form a user-friendly development environment.

zigbee gateway structure diagram
Gateway Application (developed by customers)

Feature-specific applications an be developed on the Zigbee gateway, such as device management, local control, local scenarios, OTA, northbound cloud platform docking (MQTT), and any other functions.

Gateway SDK (developable)

Encapsulate the wireless Zigbee protocol and perform protocol conversion, converting Zigbee binary data into understandable jSON format data at the application layer, allowing application programs to communicate with Zigbee more easily.

Zigbee Firmware (developable)

Responsible for southbound sub-device communication via Zigbee 3.0 and northbound SDK communication via UART.

dusun gateway full certification
Full Certification

International certifications like BQB, FCC, IC, FAC, WPC, KC, NTC, RCM, and SRRC

dusun gateway odm support
ODM support

Dusun IoT offers ODM services to turn your idea into reality.

dusun gateway fae support
FAE Support

Professional FAE team to provide in-depth gateway knowledge and technical assistance

Easy Docking with Smart Home Applications & Platforms

Zigbee hub gateway can be a prefered physical control center for smart home. Users can easily add and reset gadgets, implement third-party software control, and get feedback of Zigbee network. Dusun Zigbee gateways have open MQTT API to let users quickly connect to cloud platforms without extra programming requirement. Our programmable Zigbee gateway devices are compatible with many platforms.

For Tuya Zigbee gateway, we have Tuya Zigbee 3.0 module built-in. Welcome for inquiry.

One-stop Development for IoT Gateways, Industrial Motherboards & System on Modules. Turn IoT Device Development Process into Success.

Dusun Zigbee Gateway Use Cases

Dusun’s Zigbee Gateway, acting as a bridge connecting Zigbee to the EnOcean ecosystem, pre-installed an EnOcenan binding to receive information from end device and control actuators. It’s designed to make building more energy-efficient and achieve management of energy consumption by wireless technology
As intelligent metering devices grow in popularity, utility providers can benefit from the capabilities of Zigbee gateways, which can forward the information from the smart device to the cloud, and track water and electric use within businesses, apartments, and other households. Property companies can then bill based on the amount of water and electricity used or time of day or reward households and enterprises for conserving resources.
Using Dusun Pi series, consumers can better monitor their energy consumption and cut down on wasteful spending. With the addition of the custom module to the Dusun Pi series running the Home Assistant, any energy monitoring hardware that is compatible with the gateway can be used to collect information. Dusun Pi series is able to collect data from Z-Wave, Zigbee3.0 and Bluetooth end devices and upload it to the cloud. Users can gain valuable insights into their energy consumption and construct robust automation with its help.

Zigbee Home Automation Device Kits

All -in-one smart home start kits comes with DSGW-030 Zigbee gateway to send data from end devices to the AWS IoT Platform, PIR Motion Sensor, Door Sensor, and Smart Plug included enables customers to quickly deploy home automation Zigbee network.

Cloud Service: AWS IoT
Device Type:1 X Gateway,1 X PIR Motion Sensor, 1 X Door Sensor, 1 X Smart Plug
Industry: Home Automation, Building Automation.

Zigbee Gateway Related Resources

Easily Setup MQTT Server for Zigbee Gateways

Zigbee WiFi Gateway Connect Zigbee Switches to Control Home Gadgets

Zigbee Gateway FAQs

Zigbee gateway, as its name suggested, is an IoT gateway with Zigbee modules embeded for connecting those devices on a low bandwidth Zigbee network, and then sent data to high bandwidth TCP/IP network. It can also work as a bridge between Zigbee and Wi-Fi devices. Zigbee gateway is widely used in smart home system as home coordinator of Zigbee device network, wirelessly controlling hundreds of Zigbee compatible gadgets like home lighting, and allowing you to control your home anywhere and anytime. Learn more about what is Zigbee gateway here.

Yes, of course. The Zigbee gateway device acts as a translator between Wi-Fi networks and Zigbee network. There is no doubt that Wi-Fi is an ideal whole-home network for media streaming, browsing the web, and other data-heavy activities. But it’s a power-hungry high-bandwidth network. Many smart home product suppliers eschew Wi-Fi-connectivity because it would require their devices to have a long-lasting battery, and that would be costly for both manufacturers and consumers. While Zigbee is quite energy-saving, and enjoys good interoperability. As we mentioned in this article: What is Zigbee, a Zigbee network can be star, mesh and tree topology, whatever requires a coordinator device in charge of forming and managing the Zigbee network. A Zigbee hub gateway is so necessary to let your smart home Zigbee network communicate with the internet, so you can control things remotely with mobile phones. View more on smart home gateway importance here.

Actually, Zigbee hub and Zigbee gateway can be seen as the same thing, because they enjoy the same function. The little difference is that Zigbee hub may emphasize more on software on the gateway device, such as Amazon Echo Plus and Smartthings. While Zigbee gateway is obviously focus on the gateway hardware.  Zigbee gateway device can gather information from smart home sensors and actuators, controls them, and enables the operation of scenarios and automation systems.

There is no absolute standard for the best Zigbee gateway, everyone has its preference. Commonly, the best Zigbee gateway, as a hardware, should have robust performance on RF performance and strong signal penetration. To be compatible with smart home devices using other protocols like Z-wave and Wi-Fi, it would be suggested to have a multi-protocol gateway. On the other hand, Zigbee gateway device better have high custimization in software and applications, so that feature-complete software can be developed to meet customers’ own needs.

After you have a Dusun Zigbee gateway, using the IP from the router to access the gateway, and then enter the MQTT broker’s IP address, port number, user name, and password on the LUCI page for MQTT settings, and set the SSL option to SSL encrypt. In this manner, your preferred MQTT broker has already been connected to the Zigbee gateway. Open the MQTT.fx software and subscribe to the topic ‘t’ where the gateway published the data in order to examine the status. See more details at this guideline: How to connect to MQTT broker with SSL method in Dusun gateway.

The gateway is compatible with equipment designed in accordance with the standard for the Zigbee 3.0 protocol.

It is possible to achieve a transmission distance of 100 meters in open areas, and the indoor transmission distance depends on the specific scene.

The Dusun Zigbee protocol is compatible with a variety of networking configurations. A single Zigbee gateway can support up to 40 device connections if the network is configured as a tree. In the event that a specialized mode of mesh networking is required for a local network, a gateway has the capacity to support up to thousands of devices.

Realizing the functions of local scene linkage and local offline control can be accomplished by utilizing a home assistant gateway from the DSGW-210 series.

Through the use of the Home Assistant app, DSGW-210-HA series gateways are able to carry out local device control and gateway configuration.

Dusun offers two different docking modes for Zigbee gateways:

  • a.providing customers with an MQTT API for bidirectional communication of messages through the platform;
  • b.and b. offering a local gateway configuration page to meet the requirements of the most recent pairing test.

The Zigbee module found in Silicon Labs’ efr32 series is the one that is utilized by Dusun.

The gateway now supports the reporting of Internet of Things data on platforms such as AWS, Azure, and Google IoT. Additionally, the gateway can now serve as the foundation for open-source platforms such as OpenHAB, Jeedom, and Home Assistant.

ZigBee 3.0 cannot completely solve the problem of smart home device interoperability, but it can address the issue of application layer protocol unification. Before Zigbee 3.0, Numerous application layer protocols exist for the ZigBee protocol, and each application layer protocol is independent of the others. The primary goal of ZigBee 3.0 is to consolidate this issue. The ZigBee devices connected via various ZigBee 3.0 application layer protocols are harmonized in terms of networking, device discovery, and link joining. ZigBee 3.0 further standardizes the ZigBee protocol and makes networking with ZigBee devices more straightforward.

If the local smart tasks are established before the network interruption, they may be done properly, but the App can not operate the gateway and sub-devices.

Zigbee universal gateway is a concept in the field of smart home. Smart home solution suppliers all dream of establishing an entire smart home solution constituted of “smart module + universal control center + cloud service”, laying out their own ecosystem, and building their own smart home center, which its physical form is Zigbee universal gateway.
