Why Choose DusunIoT System on Modules
Dusun has designed various IoT Hardware based on various SoC Technology including System on Modules, IoT Gateways, and Motherboards. Today, DusunIoT’s line of multi-protocol IoT SoCs for IoT System on Module has expanded to Rockchip SoCs, MTK SoCs, NXP SoCs, etc, for embedded computing for automation, connectivity, advanced graphics, AI, imaging, machine vision, audio, voice, and video applications.
System on Modules Comparison Table
| Model | DSOM-010R_RK3328 System on Module | DSOM-050R RK3308 System on Module | DSOM-110R RK3568 System on Module | DSOM-020R PX30 System on Module | DSOM-080M MT7628N System on Module | DSOM-090M MT7621 System on Module | DSOM-060N i.MX6ULL System on Module | DSOM-070N i.MX8m System on Module |
|---|---|---|---|---|---|---|---|---|
| SoC Vendor | Rockchip | MTK | NXP | |||||
| SoC Model | RK3328 | RK3308 | RK3568 | PX30 | MT7628N | MT7621 | i.MX6ULL | i.MX8m |
| CPU | Quad-Core ARM® Cortex-A53 64-bit processor | Quad-Core ARM® Cortex-A35 64-bit processor | Quad-core 64-bit Cortex-A55, 22nm lithography process | Quad-core 64-bit Cortex-A35 | Single ARM Cortex A7 | Quad-Core ARM® Cortex-A35 | Single-core crotexA7 | Quad-core ARM Cortex-A53 |
| CPU Frequency | up to 1.5GHz | up to 1.3GHz | up to 2.0GHz | up to 1.3 GHz | 575/580MHz | 2.4GHz~2.4835GHz or 5.18GHz~5.825GHz | 792MHz | Up to 1.8 GHz |
| RAM | 2GB (1GB optional) | 512 MB DDR3/LPDDR3 (128MB/512MB optional) | 8GB （2GB/4GB/8GB LPDDR4 optional） | eMMC 32 GB (8GB/ 16GB/ 32GB/ 64GB/ 128GB eMMC optional) | DDR2 128MB, Optional 64MB | DDR3L 512MB (128MB, 256MB optional) | DDR3/ LPDDR3 standard 512M B | 2GB DDR4 (supports up to 4GB) |
| Storage | eMMC 32 GB (8GB / 16GB / 32GB / 64G / 128G eMMC optional) | eMMC 8 GB (4GB / 8GB / 16GB / 32GB/ 64G / 128G eMMC optional) | eMMC 64 GB (32GB / 64GB / 128GB eMMC optional) | RK809-1 Dynamic adjustment of the output voltage of each DC-DC converter |
16MB, Optional 32MB | eMMC 8GB( 4GB, 16GB optional) | EMMC comes standard with 8 GB | 8GB eMMC Flash (supports up to 64GB) 32MB QSPI Flash |
| OS | Android/Linux Debian + QT system | Buildroot, Linux + MiniGUI/QT, ROS (Robot Operating System) | Android/Debian/Ubuntu | Android/Debian, Buildroot, Linux + MiniGUI/QT, ROS |
Linux 2.6.36 SDK, OpenWrt 3.10 | OpenWRT | Linux( Debian, Ubuntu, .etc.) | Yocto Linux 5.4.3, Ubuntu 18.04, Android 9 |
| Temperature | -40 °C ~85 °C | -40 °C ~85 °C | -20 °C ~70 °C | -40 °C ~85 °C | -40℃~85℃ | -40℃~85℃ | -50 °C ~95 °C | -50 °C ~95 °C |
| Size | 44mm×44mm | 45mm×40.2mm | 82mm×50.5mm | 45mm×45mm | 18.7mm×35.2mm | 38mm×38mm | 38mm×38mm | 60mm×49mm |
| GPU | ARM Mali-450 MP2 Quad-Core GPU Support OpenGL ES1.1/2.0, OpenVG1.1 Frequency up to 500 MHz |
- | ARM G52 2EE Supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Embedded high-performance 2D acceleration hardware |
Embedded ARM G31-2EE GPU makes the PX30K fully compatible with OpenGL ES 1.1/2.0/3.2, DirectX 11 FL9_3, OpenCL 2.0, and Vulkan 1.0. Built-in embedded high-performance 2D acceleration hardware |
||||
| VPU | Support 4K VP9 and 4K 10bits H265 / H264 video decoding, up to 60fps 1080P multi-format video decoding(WMV, MPEG-1/2/4, VP9, H.264, H.265) 1080P video coding, support H.264/H.265 Video postprocessor: de-interlacing, denoising, edge/detail / color optimization |
- | Supports 4K 60fps H.265/H.264/VP9 video decoding Supports 1080P 60fps H.265/H.264 video encoding Supports 8M ISP, supports HDR |
LPDDR3 2GB （1GBoptional） | 2D/3D GPU and 1080p VPU | |||
| NPU | - | - | - | 0.8Tops@INT8, integrated high-performance AI accelerator RKNN NPU Supports one-click switching of Caffe/ TensorFlow/ TFLite/ ONNX/ PyTorch/ Keras/ Darknet | ||||
| Application | IoT gateways, Robotics, Facial recognition devices, Smart display terminals, Video terminals | lIoT Gateways, Smart Speakers, Smart Displays, Voice Assistants, Healthcare, Industrial Control | Industrial-embedded Linux computer, Home Appliances, Home Automation – Smart Home, Human-machine Interfaces (HMI), Point-of-sale (POS) terminals, Cash Register, 2D barcode scanners and printers, Smart grid infrastructure, IoT gateways, Residential gateways, Machine vision equipment, Robotics, Fitness/outdoor equipment | AIOT equipment, Vehicle control, Game equipment, Commercial display equipment, Medical equipment, Vending machines, Industrial computers | Industrial-embedded Linux computer, Home Appliances, Home Automation – Smart Home, IoT gateways | Routers, NAS Devices, iNICs (Intelligent Network Interface Cards), Dual Band Concurrent Band, Home Security Gateway | Industrial-embedded Linux computer, Home Appliances, Home Automation – Smart Home, Human-machine Interfaces (HMI), Point-of-sale (POS) terminals, Cash Register, 2D barcode scanners and printers, Smart grid infrastructure, IoT gateways, Residential gateways, Machine vision equipment, Robotics, Fitness/outdoor equipment | Industrial Automation, IoT Devices, Automotive Infotainment Systems, Medical Devices, Consumer Electronics, Edge AI and Machine Learning, Audio and Voice Processing, Security and Surveillance |
| I/O | All these support rich I/O Features! | |||||||
