How To Choose The Proper LoRaWAN Gateway

how to choose the proper lorawan gateway

LoRaWAN is an LPWN (low-power, wide area networking) protocol built on a physical proprietary radio communication technique, provides network protocols for network traffic related to data collection and IoT device management. LoRaWAN enables battery-powered devices to connect to the network over a long distance using extremely low bandwidth. It is appropriate for transmitting small-size packets with a long-distance communication network.

LoRaWAN Gateway works as a bridge between end users and network servers. Signal as RF packets from the end devices can be received and forwarded by the LoRaWAN gateway into LNS( LoRaWAN Network Server). With the help of the LNS, users can easily manage applications, end devices, and gateways.

Choosing the right LoRaWAN Gateway can help users build robust and reliable IoT system architecture. But a saturated market makes it challenging for a user to select the suitable LoRaWAN Gateway for his LoRaWAN development. So the following table shows a comparison between the trending LoRaWAN Gateways in the Market.



Company NameMikrotikMultitechLairdTektelic
Product Name

Mikrotik wAP LR8Multitech ConduitLaird Sentrius RG191+LTETektelic Kona Micro
Processor

QCA9531ARM9 processor with 32-Bit ARM
& 16-Bit Thumb instruction sets
Atmel A5 Core @ 536 MHz
RAM64 MB128X16M DDR RAM
Storage

16 MB/Flash256 MB Flash Memory
Micro SD max size 32GB (HSMCI),
Ethernet


1 x 10/100 Ethernet ports1 RJ-45 Ethernet 10/100 portEthernet – RJ45 ConnectorRJ-45 (10/100 BaseT)
Available wireless

Built-in 2.4 GHz 802.11b/g/n, dWi-Fi/Bluetooth/Bluetooth
Low Energy (BT/BLE), GNSS
LoRaWAN + BT/BLE+ Wi-Fi
(Optional LTE Cat 1, US only)
Backhauls


Wi-Fi 2.4G, Ethernet portBackhaul options include 4G-LTE,
3G, 2G cellular or Ethernet
for cost effective global deployment
Wi-Fi / Ethernet, or add LTE
in the US with our optional
LTE version
Ethernet,3G/4G
Integrated 3rd
party LNS
The Things NetworkThe Things NetworkThe Things Network
Chirp Stack
The Things Network


Company NameThe Things IndustriesThe Things IndustriesCiscoDragino
Product Name

The Things Indoor GatewayThe Things Outdoor GatewayCisco Wireless Gateway
for LoRaWAN
Dragino LoraWAN Gateway
Processor

1.33 GHz, single core400Mhz ar9331 processor
RAM1 GB DDR4 RAM64MB RAM
Storage

4 GB16MB Flash
Ethernet


One RJ45 Ethernet port
(10/100Mbps) with
802.3af/ at PoE
1x 10/100 Mbps
Fast Ethernet (RJ-45)
Support for PoE+ (802.3at) PD
10M/100M RJ45 Ports x 2
Available wireless

Wi-Fi 2.4GWiFi : 802.11 b/g/n
Backhauls


back-haul over 802.11 b/g/n
WiFi via ESP8266
3G/4G backhaul
via built in modem
WiFi, Ethernet, 3G or 4G
cellular network
Integrated 3rd
party LNS
The Things NetworkThe Things NetworkThe Things NetworkThe Things Network


Company NamekerlinkMielsightRAW WirelessSenseCAP
Product Name

Wirnet iStationUG67 Outdoor LoRaWAN® GatewayRAK7628 WisGate Edge LiteSenseCAP Outdoor Gateway
Processor

ARM Cortex A9Quad-core 1.5 GHz,
64-bit ARM Cortex-A53
MT7628TI AM3358 Cortex-A8 1GHz
RAMDDRAM 256MB512 MB DDR4 RAM128 MB DDRDDR3 512MB
Storage

8GB eMMC (6GB
available for user)
8 GB eMMC16 MB NOR Flash8GB eMMC
Ethernet


Ethernet 10/100 Mbps (RJ45)1 × RJ45 (PoE PD Supported)100M Base-T Ethernet with PoE100Mbps FE (RJ-45)
Available wireless

Supports 2.4 GHz Wi-Fi AP
for configuration
Backhauls


4G Worldwide module
with 3G/2G fallback
and Ethernet (RJ45)
Ethernet,4G LTE,Wi-FiMulti back-haul with Ethernet
Wi-Fi, Cellular
cellular LTE or Ethernet
Integrated 3rd
party LNS
The Things NetworkAWS, TTN, ChirpStack, Loriot,
Senet, Actility and Everyne
Private (ChirpStack)
Public (TTN) network servers

Dusun IoT LoRaWAN Gateway Advantages

Direct to Market

Our product is a Productized Gateway. It is direct to Market, just porting firmware. That means you do not need to do anything without transplanting applications before the productization.

OEM Solution Service

Our products have not only been awarded the CE and FCC certifications but also the IC, FAC, WPC, KC, NTC, RCM, and SRRC certifications. Products comply with international standards and are well-respected by customers worldwide.

Multiple-Protocol(Wire and Wireless)Supported

Coming with Zigbee3.0, Wi-Fi 2.4G/5G, BLE 5.2, GPS. Sending the captured data to the cloud with Wi-Fi and Ethernet.

Integrated with 3rd party (LNS) LoRaWAN Network Server

Our gateway has built-in integration with the LNS such as Helium, LORIOT, .etc. The benefit is that the developer can directly use the services provided by these platforms without the need to do the development. Thus accelerating IoT application development.

LoRaWAN Network Server (LNS)

The Things Network

The Things Network is a global collaborative IoT ecosystem based on the LoRaWAN. The Things Network is powered by The Things Stack, a LoRaWAN Network Server that enables the customers to connect wireless devices using the LoRaWAN protocol connectivity with The Things Network.

The advantage of using The Things Stack is reducing the cost and effort of managing applications, end devices, and gateways.

Amazon AWS

Amazon AWS, the world’s most popular platform for IoT devices, provides IoT services and solutions. It makes it easier to connect and manage billions of end devices. With the help of AWS IoT Core for LoRaWAN, a LoRaWAN Network Server, customers can easily and quickly connect end devices using the LoRaWAN protocol connectivity with the AWS cloud. The AWS IoT Core allows customers to build a private LoRaWAN network by connecting their LoRaWAN devices and gateways to the AWS cloud. The advantage of using AWS IoT Core is that customers do not need to develop and maintain their own LNS.

ChirpStack

The ChirpStack is an open-source LoRaWAN Network Server Stack, the critical component for any LoRaWAN solution. It enables you to connect LoRaWAN devices to the ChirpStack server via MQTT and TLS. This project aims to facilitate growth and creativity in the LPWAN ecosystem using the LoRaWAN protocol.

LORIOT

The LORIOT, one of the most robust, complete, and secure LoRaWAN Network Server, is designed to provide long-range IoT solution deployment anywhere in the world. In addition to proving an increasingly distributed LNS, an user-friendly software platform is also offered. The LORIOT enables individuals and businesses to build, operate, and scale their IoT network efficiently.

LoRaWAN Gatway Use Case

The LoRaWAN Gateway powered by Dusun is fully compatible with IoT applications. It has integrated with top LoRaWAN platforms such as Thingsboard, AWS IoT Core LoRaWAN, TTN, and Chirpsstack. And it has been successfully adopted into the following use cases.

LoRaWAN Gateway for Asset Tracking

Whether you’re using LoRaWAN to track customers’ beloved pets or their packages as they leave a warehouse for delivery, Dusun LoRaWAN’s wide range provides an effective way to do it. You can use your AWS IoT core LoRaWAN or another server for tracking across a long distance.

LoRaWAN gateways help logistics companies by tracking not just the positions of assets. Still, characteristics such as the speed it travels, the package’s temperature, and other industry- or asset-specific details may affect delivery.

LoRaWAN Gateway for Smart Apartment Management

As intelligent electric and water meters grow in popularity, utility providers can benefit from the capabilities of LoRaWAN gateways and track water and electric use within businesses, apartments, and other households. Companies can then bill based on the amount of water and electricity used or time-of-day, or reward households and enterprises for conserving resources.

LoRaWAN Gateway for Smart Agriculture

LoRaWAN gateways (DSGW-010C) can also make life easier and more efficient for farmers on the farm. Because it is easy to use, with the limited configuration required, fully scalable, reliable, and low-cost, more IoT specialists and do-it-yourselfers alike are deploying LoRaWAN gateways to facilitate communications between growing numbers of devices on the farm, From measuring environmental conditions that influence crop production to track livestock health indicators.

Our solution for agriculture enables efficiencies that reduce environmental impact, maximize yield and minimize expenses by improving the operation based on analyzing the data from the sensors.

Contact Dusun IoT for LoRaWAN Gateway Solutions!

Not only the above fields but also innovative health care, intelligent buildings, and other fields apply to the DUSUN LoRaWAN Gateway and its derivative solutions. Please visit https://www.dusuniot.com/ or contact us directly by email. The pre-sales engineer will give you a detailed introduction and help you discover the most suitable solution for you.

NameOutdoor LoRaWAN
Gateway
Outdoor LoRaWAN
Gateway
Outdoor LoRaWAN
Gateway
Indoor LoRaWAN
Gateway Lite
Indoor LoRaWAN
Gateway
Indoor LoRaWAN
Gateway
Indoor LoRaWAN
Gateway
ModelDSGW-010C-F-TTNDSGW-010C-F-CSDSGW-010C-LDSGW-090BDSGW-210B-F-TTNDSGW-210B-F-CSDSGW-210B-L
LoRa ChipSemtech SX1302Semtech SX1302Semtech SX1302Semtech SX1302Semtech SX1302Semtech SX1302Semtech SX1302
CPUPX30PX30PX30MT7628ANRK3328RK3328RK3328
RAMup to 2GBup to 2GBup to 2GBup to 128MBup to 2GBup to 2GBup to 2GB
Storageup to 32GBup to 32GBup to 32GBup to 32MB Flashup to 32GBup to 32GBup to 32GB
OSUbuntu, Debian,
Android
Ubuntu, Debian,
Android
Ubuntu, Debian,
Android
OpenWRTUbuntu, Debian,
Android
Ubuntu, Debian,
Android
Ubuntu, Debian,
Android
Channel PlansCN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
CN470, RU864,
IN865, EU868,
US915, AU915,
KR920, AS923
ProtocolBackhaulEthernet
Wi-Fi
Ethernet
Wi-Fi
Ethernet
Wi-Fi
Ethernet
Wi-Fi
Ethernet
Wi-Fi
Ethernet
Wi-Fi
Ethernet
Wi-Fi
DownlinkWi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Wi-Fi 2.4G/5G,
Bluetooth 5.2,
LoRaWAN, GPS
Embedded
LNS
TTN
ChirpStack
Cloud
LNS
TTN
ChirpStack
AWS IoT Core
LORIOT
