Quick View of DSGW-201 Dual Band WiFi AC1200 Router Gateway
DSGW-201 elevates your connectivity experience with a robust 880-MHz MT7621A dual-core CPU and a rich array of wireless IoT protocols, including high-speed Wi-Fi 2.4/5 GHz reaching up to an impressive 1200Mbps, BLE, Zigbee, Z-Wave, and LTE Cat4. It is also equipped with a 1000 Mbps Gigabit Ethernet port, ensuring steadfast network reliability, laying a crucial foundation for data-intensive applications.
DSGW-201 is definitely a versatile CPE device that seamlessly merges the power of an IoT gateway and a high-performance router, standing as a beacon of innovation, catering to the dynamic demands of the modern residential and SMB small to medium-sized businesses.
For simplified deployment, DSGW-201 is designed for effortlessly integration into your space. it’s built for ceiling mounting with a sleek and elegant design, easily adapting to any environment. Meanwhile, PoE support ensures hassle-free power supply, eliminating cumbersome wiring and enhancing your installation experience.
Hardware of DSGW-201 Dual Band WiFi AC1200 Router Gateway
Dimensions and Package of DSGW-201 Dual Band WiFi AC1200 Router Gateway
Parameters of DSGW-201 Dual Band WiFi AC1200 Router Gateway
| CPU | MT7621A 880MHZ Dual-Core processor |
| System | OpenWrt |
| RAM | 512MB |
| Storage | 8GB |
| TF Card | Up to 128GB |
| Power Supply | DC 12V/1.5A. The power connector features a 3.5mm aperture and a 1.35mm diameter needle with positive polarity. The power adapter is capable of 100-240V, 50/60HZ, and provides a 12V/1.5A output. |
| Reset | Factory reset button. To reset the Gateway to its original factory settings, press and hold it for more than 10 seconds |
| Network Interface | • CAT-5/CAT-5e cables for data transmission • PoE Supply with a voltage range of 44 to 57V • 1000M WAN/LAN variable port |
| USB | USB2.0 Type-C |
| SIM and TF Card slot | • Dual Slot for SIM card and TF card • Dimensions: 12mm x 15mm |
| Indicator LEDs (RGB) | 1). Power LED 2). Wireless LED 3）LTE indicator |
| Installation method | Flat, Ceiling |
| Operating Temperature | -10℃~55℃ |
| Storage Temperature | -20℃~65℃ |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 10%~90% non-condensing |
| IP rating | IP22 |
Use Cases of DSGW-201 Dual Band WiFi AC1200 Router Gateway
Resources
| Development | ||
|---|---|---|
| [QUICK START] | DSGW-201-Quick Start Guide | V1.0 |
DSGW-201 Dual Band WiFi AC1200 Router Gateway Model List
| Model | Wi-Fi 2.4G/5G | Bluetooth 5.2 | Zigbee3.0 | Z-Wave | LTE Cat4 |
|---|---|---|---|---|---|
| DSGW-201-1 | ● | ● | ● | ● | ● |
| Mdole | Wi-Fi 2.4G/5G | Bluetooth 5.2 | Zigbee3.0 | Z-Wave | LTE Cat4 |
|---|---|---|---|---|---|
| DSGW-201-2 | ● | ● |
| Model | Wi-Fi 2.4G/5G | Bluetooth 5.2 | Zigbee3.0 | Z-Wave | LTE Cat4 |
|---|---|---|---|---|---|
| DSGW-201-3 | ● |
FAQs of DSGW-201 Dual Band WiFi AC1200 Router Gateway
What is a CPE gateway
A CPE (Customer Premises Equipment) gateway, also known as a residential gateway or home gateway, is a networking device that connects a local area network (LAN) within a home or small office to the Internet Service Provider’s (ISP) network. It acts as a bridge between the devices within the home and the wider internet.
The CPE gateway typically combines several functions into a single device, making it a versatile and convenient solution for home and small business users.
CPE gateways are usually provided by the ISP to their customers as part of the internet service package. They are relatively easy to set up and offer a centralized solution for managing network connectivity and sharing internet access among multiple devices within the home or office.
What does CPE Customer Premises Equipment stand for
CPE stands for Customer Premises Equipment. It refers to the equipment and devices that are located at a customer’s premises and are used to connect to a service provider’s network. Examples of CPE include modems, routers, switches, set-top boxes, and telephony equipment. CPE is typically owned and maintained by the customer, and it is responsible for establishing and maintaining the connection to the service provider’s network.
What is the difference between 4G LTE Gateways and CPE devices?
4G LTE Gateway and CPE (Customer Premises Equipment) are both devices used to connect to a mobile network. However, there are some differences between the two:
Function: A 4G LTE Gateway is primarily used to provide internet connectivity to multiple devices in a home or office setting. On the other hand, CPE is a more general term that can refer to any equipment that connects to a service provider’s network. It can include devices used for telephony or other services, in addition to internet connectivity.
Features: 4G LTE Gateways usually have more features than CPEs. For example, they often have built-in firewalls to provide security, support for multiple wireless standards, and the ability to connect to multiple mobile networks. CPEs are usually more basic and may not have as many features.
In summary, while both 4G LTE Gateways and CPEs provide connectivity to a mobile network, 4G LTE Gateways are typically more feature-rich, while CPEs may include devices for other services beyond internet connectivity.
