Why Choose MT7628 SoCs for IoT Gateways
The DSOM-080M module, produced by Dusun Electronics, is a low-cost and low-power 300M IoT module based on MediaTek MT7628AN as the core. MediaTek MT7628 family improve the RF performance, reduce power consumption and optimize the BOM cost and make it as the best cost/performance 2×2 11n solution. MT7628K embedded with 8MB memory and provide eCos turnkey for compact router, repeater, IoT gateway bridge, storage and audio applications.
This module provides access to all the interfaces of MT7628AN, supports Linux and OpenWrt operating systems, and allows for custom development, enabling IoT Gateways based on it to easily connect to Internet of Things (IoT) appliances.
MT7628 IoT Gateways Comparison Table
| Key Features Compare | |||||
|---|---|---|---|---|---|
| Product Model | DSGW-010 | CDGW-006 | DSGW-090 | DSGW-090B | DSGW-097 |
| Image |  |
 |
 |
 |
 |
| Name | Waterproof Industrial IoT Gateway | IoT Field BUS Gateway | MTK 7628 MIPS-Based Ceiling LTE Gateway | 8-channel Indoor LoRaWAN Light Hotspot | MTK 7628 MIPS-Based EnOcean Gateway |
| CPU | DSOM-080M (MT7628) MIPS 24KEc @575/580MHz Single Core | DSOM-080M (MT7628) MIPS 24KEc @575/580MHz Single Core | DSOM-080M (MT7628) MIPS 24KEc @575/580MHz Single Core | DSOM-080M (MT7628) MIPS 24KEc @575/580MHz Single Core | DSOM-080M (MT7628) MIPS 24KEc @575/580MHz Single Core |
| RAM | Up to 128MB DDR2 | Up to 128MB DDR2 | Up to 128MB DDR2 | Up to 128MB | Up to 128MB DDR2 |
| eMMC | Up to 32MB SPI Flash | Up to 32MB Flash | Up to 32MB SPI Flash | Flash 32MB, eMMC 8GB | Up to 16MB SPI Flash |
| Protocol (Up) | LTE CatM1, Wi-Fi 2.4G/5G, Ethernet | 4G LTE, Wi-Fi 2.4G, Ethernet | LTE CatM1, Wi-Fi 2.4G, Ethernet | LTE CatM1, Wi-Fi 2.4G/5G, Ethernet | Wi-Fi 2.4G, Ethernet |
| Protocol (Down) | BLE 5.2, Zigbee 3.0, GPS | Modbus, BACnet, DMX512, BNP3 | BLE 5.2, Zigbee 3.0, Z-Wave | LoRaWAN, BLE, GPS | BLE 5.2, Zigbee 3.0, Enocean |
| Interface | RJ45 | RS485, RS232 | RJ45, Type-C, 2 X SIM Card, 1 X SD Card | RJ45, Type-C, Slot for SIM Card and SD Card | RJ45, Type-C |
| OTR | -20℃~70℃ | -10℃~55 | -10℃~55 | -10℃~60 | -10℃~55 |
| OS | OpenWRT | OpenWRT | OpenWRT | OpenWRT | OpenWRT |
| Dimension | 180mm *175mm *75mm | 120mm *90.5mm *25mm | 95mm *95mm *30mm | 95mm *95mm *30mm | 95mm *95mm *30mm |
| Certification | IP66, RoHS, FCC, CE | FCC, CE | FCC,CE , IC, Z-wave plus, RoHs | FCC, CE | FCC,CE ,IC, Z-wave plus, RoHs |
| Application | |||||
| Addtional Key Features | ThingsBoard, AWS IoT | Helium, Chirpstack, AWS IoT Core, LORIOT, TTN | EnOcean, TCM310 | ||
| Product Details | View | View | View | View | View |
| Development Resources (SDK, Firmware, Tools, Software, etc) | Get Now | Get Now | Get Now | Get Now | Get Now |
| Addtional Features Compare | |||||
| Power Supply | DC input, Power adapter, POE Power Supply |
DC 24V, 2-Pins Cresnet interface | Power Adapter, USB type-C | Power Adapter, USB type-C | Power Adapter, Micro USB |
| Battery | |||||
| Antenna | 1 x Antenna | LTE/Wi-Fi FPC Antenna | 1*external antenna (Lora), 3* internal Antenna (Wi-Fi,BLE,GPS) | ||
| Installation method | Mast, Mount | Flat, Ceiling, DIN | Ceiling | ||
